| Leoch Battery |
|---|
| Rated Voltage | 12V |
|---|
| Nominal Capacity | Nominal Capacity (25℃): C10,1.80V/cell: 65Ah |
|---|
| Dimension | Length: 348mm (13.7inches) Width: 167mm (6.57inches) Container Height:178mm (7.01inches) Total Height: 178mm (7.01inches) |
|---|
| Approx Weight | 19.2kg (42.3lbs) |
|---|
| Terminal | T6(M6) |
|---|
| Container Material | ABS (UL94 HB or V-0 optional) |
|---|
| Short-circuit current | 1495A |
|---|
| Internal Resistance | Approx 7 mΩ (Fully charged) |
|---|
| Operating Temp. Range | Discharge: -15~50℃ (5~122°F) Charge: -20~40℃ (-4~104°F) Storage: -15~40℃ (5~104°F) |
|---|
| Nominal Operating Temp. Range | 25±3℃ (77±5°F) |
|---|
| Max.Charging Current | Max.Charging Current (25℃): 0.3C |
|---|
| Charge voltage | Standby Use: 2.25-2.30V/cell Cycle Use: 2.35-2.40V/cell |
|---|
| Temp. Coeffcient | -3mV/cell/℃ -5mV/cell/℃ |
|---|
| Effect of temp. to Capacity | 40℃ (104°F): 103% 25℃ (77°F): 100% 0℃ (32°F): 86% |
|---|
| Self Discharge | ≤3% per month at 25°C (77°F). LP series batteries may be stored up to 6 months at 25°C (77°F) and then a freshening charge is required. For higher temperatures the time interval will be shorter. |
|---|
