Specification
| Battery - UPS | |
|---|---|
| Nominal Voltage | 12V |
| Nominal Capacity (20HR) | 9AH |
| Dimensions | Length: 151 ± 2mm Width: 65 ± 1mm Container Height: 93.5 ± 1mm Total Height (with Terminal): 99 ± 1mm |
| Terminal | T2 |
| Container Material | ABS |
| Max. Discharge Current | 129A (5s) |
| Internal Resistance | Approx. 19mΩ |
| Operating Temp. Range | Discharge: -15~50°C (5~122°F) Charge: 0~40°C (32~104°F) Storage: -15~40°C (5~104°F) |
| Nominal Operating Temp. Range | 25±3°C (77 ± 5°F) |
| Applications | Uninterruptable Power Supply (UPS) Electric Power System (EPS) Aircraft Signal Electronic apparatus and equipment Emergency backup power supply DC power supply |
| Standards | IEC 60896 Certified Classified as “Standard commercial” according to Eurobat UL Certified Approved as non-hazardous cargo for ground, sea, and air transportation in accordance with ICAO, IATA, and IMDG Manufactured in Leoch® Ts16949, ISO 9001, ISO 14001, and OHSAS 18001 certified production facilities. |
