Huawei eKit AP265E Wi-Fi 6 Wall Plate Dual-Radio Smart Antenna Managed PoE Access Point

Key Features

  • Model: AP265E
  • Details: Wall plate AP | Wi-Fi 6 | 2.975 Gbps device rate | Dual-radio | | 23 dBm transmit power | 4 x GE electrical ports | Smart antenna | leader AP
  • Coverage Range: 20 m optimal
  • Recommended Users: 64 access users recommended (Max. 128 access users)
  • Warranty: 3 Year Brand Warranty

Out of stock

SKU: tt-huawei-ekit-ap265e-wi-fi-6-wall-plate-dual-radio-14f2932e Categories: ,

Specification

Huawei Access Point
Wi-Fi Standard2.4 GHz: 802.11b/g/n/ax 5 GHz: 802.11a/n/ac/ac Wave 2/ax
Installation TypeDesk, Wall, Ceiling (Gypsum Board), Junction Box (86 mm/1-Gang 120 mm/Octagonal)
Optimal Signal Distance (M)20
Max Number Of Access Users128
Recommended Number Of Access Users64
Device Rate2.975 Gbps
Maximum Number Of Physical Ports On The Entire DeviceGE (RJ45) x 5, 10M/100M/1000M auto-sensing
Radio Number2
Maximum Channel Bandwidth [Mhz]Radio 0 (2.4 GHz): 40 MHz Radio 1 (5 GHz): 160 MHz
Maximum Transmit Power2.4G: 20 dBm/chain 23 dBm (combined power) 5G: 20 dBm/chain 23 dBm (combined power)
Mimo Spatial StreamsRadio 0 (2.4 GHz): 2x2 Radio 1 (5 GHz): 2x2
Maximum Power Consumption [W]9.4
Input Voltage Range [V]PoE: 802.3af
Dimensions Without Packaging (H X W X D) [Mm(In.)]160 mm x 86 mm x 38 mm (6.30 in. x 3.39 in. x 1.50 in.)
Dimensions With Packaging (H X W X D) [Mm(In.)]187 mm x 108 mm x 68 mm (7.36 in. x 4.25 in. x 2.68 in.)
Weight Without Packaging [Kg(Lb)]0.23 kg (0.51 lb)
Weight With Packaging [Kg(Lb)]0.42 kg (0.93 lb)
Long-Term Operating Temperature [°C(°F)]0°C to 40°C (32°F to 104°F) (From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.] The maximum temperature of the device decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.)
Long-Term Operating Relative Humidity [Rh]5% RH to 95% RH, non-condensing
Radio InterfaceBuilt-in smart antennas
Antenna Gain2.4G: 4 dBi/chain (peak value) 2 dBi (combined gain) 5G: 4 dBi/chain (peak value) 1 dBi (combined gain)
Operating Frequency Band2.4GHz,5GHz
Warranty03-Year Brand Warranty

Description

Huawei eKit AP265E Wi-Fi 6 Wall Plate Dual-Radio Smart Antenna Managed PoE Access Point Price in Bangladesh

Huawei eKit AP265E Wi-Fi 6 Wall Plate Dual-Radio Smart Antenna Managed PoE Access Point

Huawei eKit AP265E Wi-Fi 6 Wall Plate Dual-Radio Smart Antenna Managed PoE Access Point is a compact yet efficient wireless access point for office, hotel, and indoor small spaces. It provides Wi-Fi 6 technology with dual-band operation at 2.4 GHz (802.11b/g/n/ax) and 5 GHz (802.11a/n/ac/ac Wave 2/ax), with the total rate of devices up to 2.975 Gbps. With an ideal signal range of 20 meters, it offers fast and reliable wireless links for multiple devices.

The AP265E supports a maximum of 128 access users, and 64is  recommended for even performance. It has two radios with 2x2 MIMO on both 2.4 GHz and 5 GHz. The maximum channel bandwidth is 40 MHz on the 2.4 GHz and 160 MHz on the 5 GHz. Maximum transmit power is 23 dBm total for both bands, providing reliable coverage across working spaces. The smart antennas integrated improve signal quality with antenna gain between 4 dBi per chain for 2.4 GHz and 4 dBi per chain for 5 GHz.

There are five GE auto-sensing RJ45 ports (10M/100M/1000M) with flexible wired network connectivity. It is PoE powered with 802.3af and has a maximum power consumption of 9.4 W. The AP265E is light and small, with a size of 160 × 86 × 38 mm and a weight of 0.23 kg unpackaged. The AP265E is mountable on gypsum board for ceiling, wall, and desk mounting, including junction boxes of various sizes. The operating temperature is between 0°C to 40°C, and the humidity is between 5% and 95% non-condensing, with reliable operation under normal indoor conditions. With two radios, Wi-Fi 6 support, and smart antennas, the Huawei eKit AP265E provides fast, reliable wireless connectivity for offices, hotels, and other indoor environments and supports simultaneous multiusers and easy installation.
